xTool F2 Ultra 60W MOPA & 40W Diode Dual Laser Engraver
Book a Personalized Product Demo
xTool F2 Ultra & Diode Dual Laser
One Powerful Machine Does It All
The Ultimate Dual Laser for Any Material
60W MOPA
60W MOPA laser enables pulse and frequency control, delivering high-precision results whenever needed.
40W Diode
40W diode laser enables finer processing of non-metal materials and cuts thicker materials effortlessly.
MOPA Laser for Metals — Vibrant, Precise, and Powerful
Color Engraving Becomes More Accurate and Easier
Achieve 100+ vibrant colors on stainless steel and titanium with flawless consistency. With pre-set color files in XCS, anyone can create a custom palette and find the best settings.
Embossing Done Faster with More Detail
Under the same 100% power, xTool F2 Ultra outperforms traditional fiber lasers — delivering 3× faster speed and ultra-fine details.
2mm Metal
The 60W MOPA laser enables cutting metals up to 5 times thicker than a 20W fiber laser.
20mm Acrylic
The 40W diode laser cuts acrylic up to 20mm thick through multiple passes,delivering clean edges.
23mm Wood
The 40W diode laser cuts wood up to 23mm thick through multiple passes,delivering deeper cuts with less burning.
AI Simplifies Laser to the Max
AI Drives the Entire Process with One Click
F2 Ultra is the first AI-powered MOPA laser, built to simplify laser workflows for everyone. It auto-detects materials and applies the optimal settings for you.
Dual AI Cameras with Hawk-Eye Vision, Boosting Precision by 60%
Dual 48MP cameras boost accuracy to 0.2mm—60% improvement over single-camera systems, enabling precise work even on tiny objects like pinheads and eyeglass arms.
The Ultimate ROI Machine
Products Specification
| Specification | xTool F2 Ultra |
|---|---|
| Laser Type | F2 Ultra: 40W Diode + 60W MOPA Laser F2 Ultra (Single): 60W MOPA Laser |
| Processing Mode | Laser Engraving, Laser Cutting |
| Supported Materials | Laser Cuttable: Diode Laser: Paper, Wood, Leather, MDF, Felt, Some Dark Opaque Acrylic MOPA Laser: Brass, Stainless Steel, AluminumLaser Engravable: Diode Laser: Paper, Wood, Leather, MDF, Stainless Steel, Some Dark Opaque Acrylic, Bamboo, Fabric, Dark Glass, Ceramic, Jade, Marble, Shale, Cement, Brick, Plated Metal, Painted Metal MOPA Laser: Stainless Steel, Aluminum, Brass, Silver, Plastic, Platinum, Titanium, Gold |
| Working Area | 8.6″ × 8.6″ (220 mm × 220 mm) 8.6″ × 19.6″ (220 mm × 500 mm with conveyor) |
| Max. Working Speed | 590.55 ips (15,000 mm/s) |
| Max. Laser Cutting Capacity | Basswood: 0.91″ (23mm) in Multiple Passes Acrylic: 0.79″ (20mm) in Multiple Passes |
| Max. Processing Height | 150 mm |
| Max. Rotary Engraving Diameter | 150 mm |
| Supported Software | xTool Creative Space / Atomm |
| Operating System | Windows / macOS |
| Connection Method | USB / Wi-Fi / IP |
| Supported Files | SVG, DXF, JPG, JPEG, PNG, BMP, TIF |
| AI Make Compatibility | Yes |
| Pre-assembled | Yes |
| Built-in Camera | 48 MP Dual Cameras |
| Positioning Method | Camera Positioning |
| Focus Mode | Autofocus |
| Preview Method | Smart Camera Preview |
| Laser Spot Size | 0.09 × 0.1 mm (40W Diode Laser) 0.03 × 0.03 mm (60W MOPA Laser) |
| Positioning Precision | 0.2 mm |
| Ranging Precision | 0.2 mm (Camera) |
| Motion Accuracy | 0.00482 mm |
| Safety Certification | Class 4 Laser Safety |
| Product Size | 11.57” × 16.88” × 20.51” (294 mm × 429 mm × 521 mm) |
| Product Weight | F2 Ultra: 47 lb (21.6 kg) F2 Ultra (Single): 45 lb (20.8 kg) |
| Max. Machine Input Power | 400W |
| Power Adapter Input Voltage | 100 V – 240 V AC, 50/60 Hz |
